DS 3: DS CONNECT RADIO / First steps

DS 3 2016-2022 Owners Manual

DS 3. First steps With the engine running, a press mutes the sound.

With the ignition off, a press turns the system on. Increase or decrease the volume using the wheel or the "plus" or "minus" buttons (depending on the equipment).

Use the buttons on either side of or below the touch screen to access the menus, then press the virtual buttons on the touch screen.

At all times it is possible to display the rolling menus by pressing the screen briefly with three fingers.

All touch-sensitive areas on the screen are white.

On pages with multiple tabs at the bottom of the screen, you can switch between pages either by tapping the tab for the desired page or by swiping the pages to the left or right with your finger.

Press in the shaded area to go back up a level or confirm.

Press the back arrow to go back a level or confirm.

DS 3. First steps The touch screen is of the "capacitive" type.

To clean the screen, use a soft, non-abrasive cloth (e.g. spectacles cloth) with no additional product.

Do not use sharp objects on the screen.

Do not touch the screen with wet hands.

Certain information is displayed permanently in the upper bar of the touch screen:

  • Air conditioning status information (depending on version), and direct access to the corresponding menu.
  • Radio Media and Telephone menu status information.
  • Privacy status information.
  • Access to the touch screen and digital instrument panel settings.

Audio source selection (depending on equipment):

  • FM/DAB/AM radio stations (depending on equipment).
  • Telephone connected via Bluetooth and Bluetooth multimedia broadcast (streaming).
  • USB Memory stick.
  • Media player connected via the auxiliary socket (depending on equipment).

DS 3. First steps

DS 3. First steps In the "Settings" menu, it is possible to create a profile for an individual or for a group of people with shared interests, and configure a wide range of settings (radio presets, audio settings, ambiences, etc.). Settings are applied automatically.

DS 3. First steps In very hot conditions, the volume may be limited to protect the system. It may enter standby mode (with the screen and sound off) for 5 minutes or more.

The system will resume normal operation when the temperature in the passenger compartment has dropped.
